Future vision: event imaging and multi-shot lighting

Share this on social media:

This webcast, now on-demand, covers innovations in camera, lighting, and lens technology. An event-based camera will be presented, which takes a different imaging approach to traditional frame-based sensors, in that the sensor only activates if it detects a change in the scene. There will also be presentations on the advantages of multi-shot illumination, and how Modulation Transfer Functions of lenses can help vision system designers find optics with the best cost-to-performance ratio.
